Emotron CDU/CDX 48-008 [75/82] Emotron dsv 5445 5444

EMOTRON DSV 5445/5444

21.04.09  Emotron

Page 75

13.3 Dimensions and weight size 2 flat


DSV 5445 Size A

[mm]

Weight

[kg]

20 - 30 A 2 flat 298,5 372,5 160 11,5 268,5 291,5 6 6 367 379 155 20







DSV5445 size 2 flat is supplied without internal FU-Control.
