CHV190 series special inverter for crane
- 143 -
Fault
code
Fault type Reason Solution
2. Too low resistance
of externally
connected braking
resistor.
resistance.
-END-
Trial time reached
Trial time which
determined by factory
reached.
Contact supplier and
ask for support.
LCD-E
LCD disconnected
1. LCD disconnected.
2. Material broken
during tension control.
1. Press STOP/RST to
reset, connect LCD
then download or
upload parameter.
2. Check material.
FAE Brake feedback fault
The feedback of brake
is error,
Inspect the controlling
system of crane.
TbE
Contactor feedback
fault
The feedback of
contactor is error,
Inspect the controlling
system of crane.
TPF Torque verification fault
Torque verification is
unsuccessful.
Check torque verify.
OFE Motor speed fault
The actual motor
speed exceeds the set
speed.
Check control system
and load.
TFT Torque Monitoring fault
The monitoring of
torque is error.
Check control system
and load.
PCF
Profibus
communication fault
The communication of
Profibus is
unsuccessful.
Check Profibus
communication
module and
communication links.
ELS
Master-slave speed
synchronization fault
The position error
between master and
slave exceeds the
position bias limit
Adjust the master and
slave position and
recount the
master-slave.
STEP
Multi-step speed
rating fault
The lower
classification contact is
Please connect the
lower classification at
