CHV190 series special inverter for crane
- 194 -
APPENDIX F FUNCTON PARAMETERS
Notice:
1. PE group is factory reserved, users are forbidden to access these parameters.
2. The column “Modify” determines the parameter can be modified or not.
“○” indicates that this parameter can be modified all the time.
“ ◎ ”indicates that this parameter cannot be modified during the inverter is
running.
“●” indicates that this parameter is read only.
3. “Factory setting” indicates the value of each parameter while restoring the
factory parameters, but those detected parameters or record values cannot be
restored.
Function
Code
Name Description
Setting
Range
Factory
Setting
Modify
P0 Group: Basic function
P0.00
Speed control
mode
0: Sensorless vector
control
1: Vector control with PG
2: V/F control
0~2 1 ◎
P0.01
Run command
source
0: Keypad
(LED extinguished)
1: Terminal
(LED flickering)
2: Communication
(LED lights on)
3. Profibus
communication
(LED lights on)
0~3 1 ◎
P0.02
Speed instruction
selection
0: Keypad
1: AI1
2. AI3
3: HDI1
4: Multi-steps speed
5: UP / DOWN terminal
0~8 0 ◎
