CHV190 series special inverter for crane
- 180 -
Function code
Name Selection
Description
P0.01 Run command source 1
Terminal command
channel (LED flashing)
P0.02 Speed command source
1 AI1 setting
P1.09 Linear acceleration time
4.0s Acceleration time
P1.10 Linear deceleration time
4.0s Deceleration time
P5.01 S4, S5 input type 0 ON/OFF input
P5.02 S1 terminal function 1 Forward (FWD)
P5.03 S2 terminal function 2 Reverse (REV)
P5.04 S3 terminal function 7 Fault reset (RET)
P6.04 Relay 1 output 4 Fault output
P6.05 Relay 2 output 7 Brake output
P6.07 AO1 output 0 Running frequency
P6.08 AO2 output 4 Current output
P8.04 Brake, contactor control
1
Brake is controlled by
inverter
P8.16 Inverter stop delay time 0.25s Delay time of stop
PA.06
485 communication
protocol selection
1
Internal master-slave
control protocol
Pb.00
Master-slave type
selection
2
Speed synchronous
mode
Pb.01
Master-slave mode
selection
1 The master
Pb.04
Data sending of host
communication enable
1
CAN communication
sending
B.9 Master-slave Speed Synchronization Slave Mode
If set P0.11=9, the master-slave speed synchronization slave mode is valid when the
inverter of the master-slave speed synchronization control mode is slave under master-
slave speed synchronization slave mode.
Fault output of the slave should be connected to the external fault terminal of the host
Master-slave speed synchronous slave mode parameter settings are as follows:
Function code
Name Function
Description
P0.01 Run command channel 1
Terminal command
channel (LED flashing)
