CHV190 series special inverter for crane
- 191 -
APPENDIX E SPECIFICATIONS OF ACCESSORIES
E.1 Specifications of Breaker, Cable, Contactor and Reactor
E.1.1 Specifications of breaker, cable and contactor
Model No. Circuit breaker (A)
Input/Output cable
(mm
2
)
(Coppery wire)
Rated current of
contactor (A)
(380V or 220V)
CHV190-018G-4
100 10 63
CHV190-022G-4
100 16 80
CHV190-030G-4
125 25 95
CHV190-037G-4
160 25 120
CHV190-045G-4
200 35 135
CHV190-055G-4
200 35 170
CHV190-075G-4
250 70 230
CHV190-090G-4
315 70 280
CHV190-110G-4
400 95 315
CHV190-132G-4
400 150 380
CHV190-160G-4
630 185 450
CHV190-185G-4
630 185 500
CHV190-200G-4
630 240 580
CHV190-220G-4
800 150x2 630
CHV190-250G-4
800 150x2 700
CHV190-280G-4
1000 185x2 780
CHV190-315G-4
1200 240x2 900
CHV190-350G-4
1280 240x2 960
CHV190-400G-4
1380 185x3 1035
CHV190-500G-4
1720 185x3 1290
E.1.2 Specifications of AC input/output and DC reactor
AC input reactor AC output reactor
DC reactor
Model No.
Current
(A)
Inductance
(mH)
Current
(A)
Current
(A)
Inductance
(mH)
Current
(A)
CHV190-018G-4
50 0.35 50 0.052
40 1.3
