CHV190 series special inverter for crane
- 176 -
Function code
Name Selection
Description
P8.04 Brake, contactor control
1
Brake is controlled by
inverter
P8.16 Inverter stop delay time 0.25s Delay time of stop
Pb.00 Master-slave type 1 Power balance model
Pb.01 Master-slave mode 1 The slave
Pb.04
Data sending of host
communication enable
1
CAN communication
sending
B.7 Master-slave Power Equilibrium Slave Mode
If set P0.11=7, the master-slave power equilibrium slave mode is valid when the inverter of
the master-slave power equilibrium control mode is slave under master-slave power
equilibrium slave mode.
Direction and speed commands of crane are given by the host.
Fault output of the slave should be connected to the external fault terminal of the host.
Master-slave power equilibrium slave mode parameter settings are as follows:
Function code
Name Selection
Description
P0.01 Run command source 1
Terminal command
channel (LED flashing)
P0.02 Speed command source
1 AI1 setting
P1.09 Linear acceleration time
4.0s Acceleration time
P1.10 Linear deceleration time
4.0s Deceleration time
P5.01 S4, S5 input type 0 ON/OFF input
P5.04 S3 terminal function 7 External fault (EF)
P5.08 S7 terminal function 19
Master-slave enable
(need I/O extension
card)
P6.04 Relay 1 output 4 Fault output
P6.05 Relay 2 output 7 Brake output
P6.07 AO1 output 0 Running frequency
P6.08 AO2 output 4 Current output
P8.04 Brake, contactor control
1
Brake is controlled by
inverter
P8.16 Inverter stop delay time 0.25s Delay time of stop
Pb.00 Master-slave type 1 Power balance model
