Metabo TS 36-18 LTX BL 254 (613025810) [15/152] English en

ENGLISH en

b) Always use saw blade guard and riving

knife for every through-cutting operation. For

through-cutting operations where the saw blade

cuts completely through the thickness of the

workpiece, the guard and other safety devices

help reduce the risk of injury.

c) Immediately reattach the guarding system

after completing an operation (such as

rabbeting) which requires removal of the

guard and riving knife. The guard, riving knife

help to reduce the risk of injury.

d) Make sure the saw blade is not contacting

the guard, riving knife or the workpiece

before the switch is turned on. Inadvertent

contact of these items with the saw blade could

cause a hazardous condition.

e) Adjust the riving knife as described in this

instruction manual. Incorrect spacing,

positioning and alignment can make the riving

knife ineffective in reducing the likelihood of

kickback.

f) For the riving knife to work, they must be

engaged in the workpiece. The riving knife is

ineffective when cutting workpieces that are too

short to be engaged with the riving knife and anti-

kickback device. Under these conditions a

kickback cannot be prevented by the riving knife

and anti- kickback device.

g) Use the appropriate saw blade for the

riving knife. For the riving knife to function

properly, the saw blade diameter must match the

appropriate riving knife and the body of the saw

blade must be thinner than the thickness of the

riving knife and the cutting width of the saw blade

must be wider than the thickness of the riving

knife.

4.2 Cutting procedures warnings

a) DANGER: Never place your fingers or

hands in the vicinity or in line with the

saw blade. A moment of inattention or a slip

could direct your hand towards the saw blade and

result in serious personal injury.

b) Feed the workpiece into the saw blade

only against the direction of rotation. Feeding

the workpiece in the same direction that the saw

blade is rotating above the table may result in the

workpiece, and your hand, being pulled into the

saw blade.

c) Never use the mitre gauge to feed the

workpiece when ripping and do not use the

rip fence as a length stop when cross cutting

with the mitre gauge. Guiding the workpiece

with the rip fence and the mitre gauge at the same

time increases the likelihood of saw blade binding

and kickback.

d) When ripping, always apply the workpiece

feeding force between the fence and the saw

blade. Use a push stick when the distance

between the fence and the saw blade is less

than 150 mm, and use a push block when this

distance is less than 50 mm. "Work helping"

devices will keep your hand at a safe distance

from the saw blade.

e) Use only the push stick provided by the

manufacturer or constructed in accordance

with the instructions. This push stick provides

sufficient distance of the hand from the saw

blade.

f) Never use a damaged or cut push stick. A

damaged push stick may break causing your

hand to slip into the saw blade.

g) Do not perform any operation "freehand".

Always use either the rip fence or the mitre

gauge to position and guide the workpiece.

"Freehand" means using your hands to support or

guide the workpiece, in lieu of a rip fence or mitre

gauge. Freehand sawing leads to misalignment,

binding and kickback.

h) Never reach around or over a rotating saw

blade. Reaching for a workpiece may lead to

accidental contact with the moving saw blade.

i) Provide auxiliary workpiece support to the

rear and/or sides of the saw table for long

and/or wide workpieces to keep them level. A

long and/or wide workpiece has a tendency to

pivot on the table's edge, causing loss of control,

saw blade binding and kickback.

j) Feed workpiece at an even pace. Do not

bend or twist the workpiece. If jamming

occurs, turn the tool off immediately, unplug

the tool then clear the jam. Jamming the saw

blade by the workpiece can cause kickback or

stall the motor.

k) Do not remove pieces of cut-off material

while the saw is running. The material may

become trapped between the fence or inside the

saw blade guard and the saw blade pulling your

fingers into the saw blade. Turn the saw off and

wait until the saw blade stops before removing

material.

l) Use an auxiliary fence in contact with the

table top when ripping workpieces less than

2 mm thick. A thin workpiece may wedge under

the rip fence and create a kickback.

4.3 Kickback causes and related warnings

Kickback is a sudden reaction of the workpiece

due to a pinched, jammed saw blade or

misaligned line of cut in the workpiece with

respect to the saw blade or when a part of the

workpiece binds between the saw blade and the

rip fence or other fixed object.

Most frequently during kickback, the workpiece is

lifted from the table by the rear portion of the saw

blade and is propelled towards the operator.

Kickback is the result of saw misuse and/or

incorrect operating procedures or conditions and

can be avoided by taking proper precautions as

given below.

a) Never stand directly in line with the saw

blade. Always position your body on the

same side of the saw blade as the fence.

Kickback may propel the workpiece at high

velocity towards anyone standing in front and in

line with the saw blade.

b) Never reach over or in back of the saw

blade to pull or to support the workpiece.

Accidental contact with the saw blade may occur

or kickback may drag your fingers into the saw

blade.

c) Never hold and press the workpiece that is

being cut off against the rotating saw blade.

Pressing the workpiece being cut off against the

saw blade will create a binding condition and

kickback.

Align the fence to be parallel with the saw

blade. A misaligned fence will pinch the

workpiece against the saw blade and create

kickback.

e) Use a featherboard to guide the workpiece

against the table and fence when making

non-through cuts such as rabbeting. A

featherboard helps to control the workpiece in the

event of a kickback.

f) Support large panels to minimise the risk of

saw blade pinching and kickback. Large

panels tend to sag under their own weight.

Support(s) must be placed under all portions of

the panel overhanging the table top.

g) Use extra caution when cutting a

workpiece that is twisted, knotted, warped or

does not have a straight edge to guide it with

a mitre gauge or along the fence. A warped,

knotted, or twisted workpiece is unstable and

causes misalignment of the kerf with the saw

blade, binding and kickback.

h) Never cut more than one workpiece,

stacked vertically or horizontally. The saw

blade could pick up one or more pieces and

cause kickback.

i) When restarting the saw with the saw blade

in the workpiece, centre the saw blade in the

kerf so that the saw teeth are not engaged in

the material. If the saw blade binds, it may lift up

the workpiece and cause kickback when the saw

is restarted.

j) Keep saw blades clean, sharp, and with

sufficient set. Never use warped saw blades

or saw blades with cracked or broken teeth.

Sharp and properly set saw blades minimise

binding, stalling and kickback.

4.4 Table saw operating procedure

warnings

a) Turn off the table saw and disconnect from

the battery pack when removing the table

insert, changing the saw blade or making

adjustments to the riving knife or saw blade

guard, and when the machine is left

unattended. Precautionary measures will avoid

accidents.

b) Never leave the table saw running

unattended. Turn it off and don't leave the

tool until it comes to a complete stop. An

unattended running saw is an uncontrolled

hazard.

c) Locate the table saw in a well-lit and level

area where you can maintain good footing

and balance. It should be installed in an area

that provides enough room to easily handle

the size of your workpiece. Cramped, dark

areas, and uneven slippery floors invite

accidents.

d) Frequently clean and remove sawdust

from under the saw table and/or the dust

collection device. Accumulated sawdust is

combustible and may self-ignite.

e) The table saw must be secured. A table saw

that is not properly secured may move or tip over.

f) Remove tools, wood scraps, etc. from the

table before the table saw is turned on.

Distraction or a potential jam can be dangerous.

g) Always use saw blades with correct size

and shape (diamond versus round) of arbour

holes. Saw blades that do not match the

mounting hardware of the saw will run off-centre,

causing loss of control.

h) Never use damaged or incorrect saw blade

mounting means such as flanges, saw blade

washers, bolts or nuts. These mounting means

were specially designed for your saw, for safe

operation and optimum performance.

Never stand on the table saw, do not use it

as a stepping stool. Serious injury could occur if

the tool is tipped or if the cutting tool is

accidentally contacted.

j) Make sure that the saw blade is installed to

rotate in the proper direction. Do not use

grinding wheels, wire brushes, or abrasive

wheels on a table saw. Improper saw blade

installation or use of accessories not

recommended may cause serious injury.

4.5 Additional Safety Instructions

– These operating instructions are intended for

people with basic technical knowledge

regarding the operation of a machine like this or

similar electrical power tools. Inexperienced

persons are strongly advised to seek competent

advise and guidance from an experienced

person before operating this machine.

– The manufacturer assumes no liability for any

damage caused by neglect of these operating

instructions.

Information in these instructions is marked as

under:

Danger!

Risk of personal injury or environ-

mental damage.

Risk of electric shock!

Risk of personal injury by electric

shock.

Entanglement hazard!

Risk of personal injury by body parts

or clothing being drawn into the ro-

tating saw blade.

Caution!

Risk of material damage.

Note:

Additional information.

 Please also observe the special safety

instructions in the respective chapters.

 Where applicable, follow the legal directives or

regulations for the prevention of accidents

pertaining to the use of circular saws.

General hazards!

 Consider environmental conditions:

 When working long stock use suitable supports.

 The saw shall only be started and operated by

persons familiar with circular saws and who are

at any time aware of the dangers associated

with the operation of such tools.

Persons under 18 years of age shall use this

machine only in the course of their vocational

training, under the supervision of an instructor.

Metabo TS 36-18 LTX BL 254 (613025810) [15/152] English en
