AXIS 212 PTZ/-V - Video Streams

Alternative methods of accessing the video stream

Video/images from AXIS 212 PTZ/-V can also be accessed in the following ways:

• If supported by the client, AXIS 212 PTZ/-V can use Motion JPEG server push to display video. This option maintains an

open HTTP connection to the browser and sends data as and when required, for as long as required.

• As single JPEG images in a browser. Enter, for example, the path: http://<ip>/axis-cgi/jpg/image.cgi?resolution=CIF

• Windows Media Player. This requires AMC and the MPEG-4 decoder to be installed. The paths that can be used are

listed below, in the order of preference.

• Unicast via RTP: axrtpu://<ip>/mpeg4/media.amp

• Unicast via RTSP: axrtsp://<ip>/mpeg4/media.amp

• Unicast via RTSP, tunneled via HTTP: axrtsphttp://<ip>/mpeg4/media.amp

• Unicast via RTSP, tunneled via HTTPS: axrtsphttps://<ip>/mpeg4/media.amp

• Multicast: axrtpm://<ip>/mpeg4/media.amp

Note:

<ip> = IP address
