34
AXIS 212 PTZ/-V - System Options
AXIS Internet Dynamic DNS Service - use AXIS Internet Dynamic DNS service to assign a host name for easy access to your
AXIS 212 PTZ/-V (requires Internet access).
Click Settings to register your AXIS 212 PTZ/-V with AXIS Internet Dynamic DNS service, or to modify the existing settings
(requires access to the Internet). The domain name currently registered at AXIS Internet Dynamic DNS service for your product
can be removed at any time.
For more information, please refer to the online help.
Advanced TCP/IP Settings
DNS Configuration - DNS (Domain Name Service) provides the translation of host names to IP addresses on your network.
Obtain DNS server address via DHCP - automatically use the DNS server settings provided by the DHCP server. Click the View
button to see the current settings.
Use the following DNS server address - enter the desired DNS server by specifying the following:
• Domain name - enter the domain(s) to search for the host name used by AXIS 212 PTZ/-V. Multiple domains can be
separated by semicolons (;). The host name is always the first part of a Fully Qualified Domain Name, for example,
myserver is the host name in the Fully Qualified Domain Name myserver.mycompany.com where mycompany.com is
the Domain name.
• Primary DNS server - enter the IP address of the primary DNS server.
• Secondary DNS server - will be used if the primary DNS server is unavailable.
Domain name - enter the domain(s) to search for the host name used by AXIS 212 PTZ/-V. Multiple domains can be separated
by semicolons (;). The host name is always the first part of a Fully Qualified Domain Name, for example, myserver is the host
name in the Fully Qualified Domain Name myserver.mycompany.com where mycompany.com is the Domain name.
DNS servers - enter the IP addresses of the primary and secondary DNS servers.
NTP Configuration - Obtain NTP server address via DHCP - check this radio button to automatically look up and use the NTP
server settings as provided by DHCP. Click the View button to see the current settings.
Use the following NTP server address - to make manual settings, check this radio button and enter the host name or IP
address of the NTP server.
Host Name Configuration - AXIS 212 PTZ/-V can be accessed using a host name, instead of an IP address. The host name is
usually the same as the assigned DNS Name. It is always the first part of a Fully Qualified Domain Name and is always one
word, with no period. For example, myserver is the host name in the Fully Qualified Domain Name myserver.mycompany.com.
Enabling dynamic DNS updates allows you to alias a dynamic IP address to a static host name, allowing your computer to be
more easily accessed from various locations on the Internet. Outside users can always access your server using the associated
DNS name regardless of the WAN IP. The DNS server used by the user and/or the DNS server responsible for the domain in use
must support RFC2136 and allow updates from the camera.
The TTL (Time To Live) value determines how long (in seconds) the reply from the DNS server should be remembered when
checking that the domain name for the registered IP address is still valid.
Link-Local IPv4 Address - Link-Local Address is enabled by default and assigns AXIS 212 PTZ/-V an additional IP address for
the UPnP protocol. AXIS 212 PTZ/-V can have both a Link-Local IP and a static/DHCP IP address at the same time - these will
not affect each other. See UPnP™, on page 37.
HTTP - The default HTTP port number (80) can be changed to any port within the range 1024-65535. This is useful for
example, simple security port mapping.
HTTPS - The default HTTPS port number (443) can be changed to any port within the range 1024-65535. HTTPS is used to
provide encrypted web browsing.
