23
AXIS 212 PTZ/-V - Live View Config
Default Viewer
From the drop-down lists, select the default method for viewing video images for your browser. The camera will attempt to
show the video images in the selected video format and viewer. If this is not possible, the camera will override the settings
and select the best available combination.
Viewer Settings
Show viewer toolbar - Check this box to display the viewer toolbar under the image in your browser. The toolbar provides
various controls for pausing the video stream, and switching to full screen mode.
Enable MPEG-4 decoder installation - By checking/unchecking this box, the administrator can enable or disable the
installation of the MPEG-4 decoder included with AMC. This is used to prevent the installation of unlicensed copies. Further
decoder licenses can be purchased from your Axis dealer.
Show crosshair in PTZ joystick mode - This cross indicates the center of the image when viewing the video stream in PTZ
joystick mode.
Use PTZ joystick mode as default - Enabling this sets the PTZ mode to joystick. The mode can be changed temporarily on the
PTZ Control Panel, but will default to joystick if this is selected.
Enable recording button - Enabling this button allows the user to start a recording directly from the Live View page. The
recording is saved in the folder specified in the Recording tab in the AMC Control Applet. Note that this button is only
available when viewing with AMC.
Action Buttons
Show manual trigger button - When displayed on the Live View page, clicking these buttons (On and Off) manually starts
and stops all events that are configured to trigger in this way.
Show snapshot button - Enabling the display of the Snapshot button allows users to save a Motion JPEG snapshot from the
video stream by clicking the button. This button is mainly intended for use with browsers other than Internet Explorer (IE), or
when otherwise not using AXIS Media Control (AMC) to view the video stream. AMC provides its own snapshot button.
Browser Viewer Description
Windows
Internet Explorer
AMC Recommended viewer in Windows Internet Explorer (MPEG-4 / Motion JPEG).
QuickTime MPEG-4 only.
Java applet A slower imaging alternative to AMC. Requires one of the following installed on
the client:
• JVM (J2SE) 1.4.2 or higher
• JRE (J2SE) 5.0 or higher
Still image Displays still images only. Hit the Refresh button in your browser to view a new
image.
Other browsers
Server Push Recommended viewer for other browsers (Motion JPEG).
QuickTime MPEG-4 only.
Java applet A slower imaging alternative to Server Push (Motion JPEG only).
Still image Displays still images only. Hit the Refresh button in your browser to view a new
image.
