48
AXIS 212 PTZ/-V - Technical Specifications
Casing • AXIS 212 PTZ: Polycarbonate base and polycarbonate transparent cover
• AXIS 212 PTZ-V: 1000 kg (2200 lbs) impact-resistant casing with metal base and rugged
polycarbonate transparent cover
• Tamper-proof mounting on wall, hard or drop ceiling
Processors and
memory
• CPU, video processing and compression: ARTPEC-A
• RAM: 32 MB
• Flash memory: 8 MB
• Battery backed-up real-time clock
Power • 4.9-5.1 V DC max 3.6 W
• Power over Ethernet (IEEE 802.3af) Class 1 (max 3.84 W)
Operating
conditions
• Temperature: +5 to +40º C (41 – 104 ºF)
• Humidity: 20-80% RH (non-condensing)
Installation,
management and
maintenance
• AXIS Camera Management tool on CD and Web-based configuration
• Configuration of backup and restore
• Firmware upgrades over HTTP or FTP, firmware available at www.axis.com
Video access from
web browser
• Camera live view
• Video recording to file (ASF)
• Sequence tour for up to 20 PTZ presets or external Axis video sources
• Customizable HTML pages
Minimum
requirements
• Pentium III CPU 500 MHz or higher, or equivalent AMD
• 128 MB RAM
• AGP graphics card, 32 MB RAM
• Direct Draw
• Windows XP, 2000
• DirectX 9.0 or later
• Internet Explorer 6.x or later
For other operating systems and browsers see www.axis.com/techsup
System
integration
support
• Open API for application integration including AXIS VAPIX API*, AXIS Media Control SDK*
• Event trigger data in video stream
• Quality of Service (QoS) Layer 3, DiffServ Model
• Embedded Linux operating system
* Available at www.axis.com
Supported
protocols
IPv4/v6, TCP, ICMP, ARP, RTSP, RTP, RTCP, UDP, IGMP, DHCP, DNS, DynDNS, SOCKS, NTP, UPnP,
Bonjour, HTTP, HTTPS, SSL/TLS*,SNMPv1/v2c/v3 (MIB-II), SMTP, FTP. More information on protocol
usage available at http://www.axis.com
* This product includes software developed by the Open SSL Project for use in the Open SSL Tool kit
(www.openssl.org)
Included
accessories
• Installation Guide
• CD with installation and management tools, demo software and User’s Manual
• Mounting and connector kits
• Angled wall mount
• Power supply PS-H 5.1 V DC
• licenses for 1 encoder and 1decoder,
• decoder software for Windows
Accessories Not
Included
AXIS 295 Video Surveillance Joystick
Multi-user decoder license pack
Video
management
software
(not included)
AXIS Camera Station - Surveillance application for viewing, recording and archiving up to 25 cameras
See www.axis.com/partner/adp_partners.htm for further software applications via partners
Item Specification
