33
AXIS 212 PTZ/-V - System Options
Date & Time
Current Server Time - displays the current date and time (24h clock). The time can be displayed in 12h clock format in the
Overlay (see below).
New Server Time - Select your time zone from the drop-down list. If you want the server clock to automatically adjust for
daylight savings time, select Automatically adjust for daylight saving time changes.
From the Time Mode section, select the preferred method to use for setting the time:
• Synchronize with computer time - sets the time from the clock on your computer.
• Synchronize with NTP server - the camera will obtain the time from an NTP server every 60 minutes.
• Set manually - this option allows you to manually set the time and date.
Note:
If using a host name for the NTP server, a DNS server must be configured under TCP/IP settings.
See Network > TCP/IP below.
Date & Time Format Used in Images - specify the formats for the date and time (12h or 24h) displayed in the video streams.
Use the predefined formats or use your own custom date and time formats. See Advanced File Naming & Date/Time Formats
in the online help for information on how to create your own file formats.
Network
Basic TCP/IP Settings
IP Address Configuration - AXIS 212 PTZ/-V supports both IP version 4 and IP version 6. Both versions may be enabled
simultaneously, and at least one version must always be enabled.
When using IPv4, the IP address can be set automatically via DHCP, or a static IP address can be set manually.
If IPv6 is enabled, your camera will receive an IP address according to the configuration in the network router.
There are also options for setting up notification of changes in the IP address, and for using AXIS Internet Dynamic DNS
Service. For more information on setting the IP address, please see the online help.
Notes:
• To receive notification whenever the camera’s IP address changes (via for example, DHCP), configure the
options for notification of IP address change. See Services below.
• Alternatively, if your DHCP server can update a DNS server, you can access the AXIS 212 PTZ/AXIS 212 PTZ-V
by host name which is always the same, regardless of the IP address.
Services - Enable ARP/Ping setting of IP address - The IP address can be set using the ARP/Ping method, which associates
the unit's MAC address with an IP address. Check this box to enable the service. Leave disabled to prevent unintentional
resetting of the IP address.
Notes:
• The ARP/Ping service is automatically disabled 2 minutes after the unit is started, or as soon as an IP address
is set.
• Pinging the unit will still be possible when this service is disabled.
Options for notification of IP address change - if the IP address for the camera changes, for example, automatically by
DHCP, you can choose to be notified of the change. Click Settings... and enter the required information.
