• Chillers • R-407C • EUWAC-FZW
1
13
• Applied Systems • Chillers
24
13 Hydraulic performance
13 - 2 Water pressure drop curve condenser
3TW55058-1
ESP/PI - AF of EUWAC5FZW
NOTES
1 ESP = External static pressure
PI = power input of the fans
AF = airflow of the fans
2 Values applicable for no headpressure control working only.
