Daikin EUWAC8FZW [8/26] Specifications
![Daikin EUWAC8FZW [8/26] Specifications](/views2/1657182/page8/bg8.png)
3
1
3
• Applied Systems • Chillers
9
• Chillers • R-407C • EUWAC-FZW
3 Specifications
3-1 TECHNICAL SPECIFICATIONS EUWAC5FZW1 EUWAC8FZW1 EUWAC10FZW1
Capacity
(Eurovent)
Cooling Nominal kW 11.60 18.40 23.80
Capacity Steps % 100-0
Nominal input
(Eurovent)
Cooling kW 5.25 7.78 9.85
Casing Colour Ivory white/Munsell code 5Y7.5/1
Material Polyester coated galvanised steel
Dimensions Unit Height mm 1345 1290 1395
Width mm 856 1180 1330
Depth mm 630 630 630
Weight Unit kg 164 224 261
Operating Weight kg 166 228 266
Air heat
exchanger
Type Cross fin coil/Hi-X tubes and PE coated waffle louvre fins
Rows 3 3 3
Stages 6+2 11+2 13+2
Fin Pitch mm 2.00 2.00 2.00
Face Area m² 0.47 0.77 0.95
Water Heat
Exchanger
Evaporator
Type Brased plate, one per circuit
Minimum water volume in
the system
l 101 153 212
Water flow rate Min l/min 16 23 28
Nominal l/min 33 53 68
Max l/min 64 92 112
Insulation material PVC nitril foam
Model Quantity 1 1 1
Model AC50-24 AC50-34 AC50-40
Fan Type Centrifugal
Drive Direct drive Belt drive Belt drive
Nominal air flow m³/min 1.17 1.83 2.10
External static
pressure
Max Pa 100 150 150
Model Quantity 1 1 1
Discharge direction Horizontal
Compressor Type Hermetically sealed scroll compressor
Refrigerant oil type Daphne FVC68D
Refrigerant oil charge l 1.5 2.7 2.7
Model Quantity 1 1 1
Model JT140BF-YE JT212DA-YE JT265DA-YE
Speed rpm 2900 2900 2900
Sound level Sound Power Cooling dBA 63 66 69
Refrigerant
circuit
Refrigerant type R-407C
Refrigerant charge kg 2.1 3.9 4.7
N2 holding charge No
No of circuits 1 1 1
Refrigerant control Thermostatic expansion valve
Piping
connections
Evaporator water inlet/outlet FBSP 1’’
field installation
Safety Devices High pressure switch
Evaporating temperature protection
Discharge temperature protector
Outlet water temperature protection
Compressor motor overcurrent relay
Fan thermal protector
Anti-recycling and guard timer
Reverse phase protector
DDC with electronic temperature control
Internal fuses
Low pressure switch
