ESIE05-07 Test Run and Operation Data

Part 4 – Commissioning and Test Run 4–25

2.6 Test Run and Operation Data for ERAP110~170MBYNN

Pressures The table below contains the measurable pressures.

Temperatures The table below contains the measurable temperatures.

Voltages The table below contains the measurable voltages.

Currents The table below contains the currents and used fuses.

Recommended fuses according to IEC standard 269-2: gL/gG (aM also admitted)

(F1U, F2U, F3U = gL/gG)

Measurement Value

Suction pressure

depending on working conditions

Discharge pressure

Maximum water pressure 10 bar

Measurement Value

Evaporating temperature (suction dew point) -15 – 11°C

Outdoor temperature -15 – 43°C for standard unit

Temperature difference at the air side 10 – 15°C

Temperature difference at the water side 3 – 8°C

Discharge temperature 80 – 120°C

Measurement Value

Power supply voltage Within ± 10% of the rated voltage

Phase imbalance Within ± 2% of the rated voltage

Control circuit voltage 230 V AC for main electromagnetic switches

24 V DC for the controllers

Unit Nominal current Maximum current Fuses

ERAP110MBYNN 70 A 95 A 3 x 125 gL A

ERAP150MBYNN 84 A 120 A 3 x 160 gL A

ERAP170MBYNN 104 A 135 A 3 x 160 gL A
