Fluke FLK-116 [23/24] True rms multimeter general specifications

True-rms Multimeter

General Specifications

Table 1 Accuracy Specifications (cont.)

Function Range Resolution

Accuracy

± ([% of Reading] + [Counts])

AC μAmps True-rms

[1]

(45 Hz to 1 kHz)

600.0 μA 0.1 μA

1.5 % + 3

(2.5 % + 3 >500 Hz)

DC μAmps 600.0 μA 0.1 μA 1.0 % + 2

Hz (V input)

[3]

99.99 Hz

999.9 Hz

9.999 kHz

50.00 kHz

0.01 Hz

0.1 Hz

0.001 kHz

0.01 kHz

0.1 % + 2

Notes:

[1] All AC ranges except Auto-V LoZ are specified from 1 % to 100% of range. Auto-V LoZ is specified from 0 V.

Because inputs below 1 % of range are not specified, it is normal for this and other true-rms meters to display non-

zero readings when the test leads are disconnected from a circuit or are shorted together. For volts and μA, crest

factor of ≤3 at 4000 counts, decreasing linearly to 1.5 at full scale. AC volts is ac-coupled. Auto-V LoZ, AC mV, and

AC μA are dc-coupled.

[2] Temperature uncertainty (accuracy) does not include the error of the thermocouple probe.

[3] Frequency is ac coupled and specified from 5 Hz to 50 kHz.
