116
Users Manual
6
Terminals
COM
+
1
2
edy01f.eps
No. Description
A Common (return) terminal for all measurements.
B
Input terminal for measuring voltage, continuity, resistance, capacitance, frequency, temperature,
microamps and testing diodes..
Error Messages
bAtt Battery must be replaced before the Meter will operate.
CAL Err Calibration required. Meter calibration is required before the Meter will operate.
EEPr Err Internal error. The Meter must be repaired before it will operate.
F11Err Internal error. The Meter must be repaired before it will operate.
