Fluke FLK-116 [9/24] Rotary switch positions
![Fluke FLK-116 [9/24] Rotary switch positions](/views2/1664825/page9/bg9.png)
True-rms Multimeter
Rotary Switch Positions
7
Rotary Switch Positions
Switch Position Measurement Function
x
Automatically selects ac or dc volts based on the sensed input with a low impedance
input.
e
Hz (button)
AC voltage from 0.06 to 600 V.
Frequency from 5 Hz to 50 kHz.
D
DC voltage from 0.001 V to 600 V.
l
AC voltage from 6.0 to 600 mV, dc-coupled.
DC voltage from 0.1 to 600 mV.
Ω
Ohms from 0.1 Ω to 40 MΩ.
s
Continuity beeper turns on at <20 Ω and turns off at >250 Ω.
y
Temperature from -40 °C to 400 °C (-40 °F to 752 °F) with K-type thermocouple
R
Diode Test. Displays OL above 2.0 V.
S
Farads from 1 nF to 9999 μF.
$
DC current from 0.1 to 600 μA. AC current from 6.0 to 600 μA. DC-coupled.
Note: All ac functions and Auto-V LoZ are true-rms. AC voltage is ac-coupled. Auto-V LoZ, AC mV and AC μA
are dc coupled.
