True-rms Multimeter
Display
5
No. Symbol Meaning
F M
VWX
MIN MAX AVG mode enabled.
Maximum, minimum, average or present reading displayed
G LoZ The Meter is measuring voltage or capacitiance with a low input impedance.
H nµ°F°C mVµA
MkΩ kHz
Measurement units.
I DC AC Direct current or alternating current
J N Battery low warning.
K 610000 mV Indicates the Meter’s range selection.
L (Bar graph) Analog display.
M Auto Volts
Auto
Manual
The Meter is in the Auto Volts function.
Auto ranging. The Meter selects the range for best resolution.
Manual ranging. User sets the Meter’s range.
N + Bar graph polarity
O 0L W The input is too large for the selected range.
P 0PEn Thermocouple missing or defective when Temperature function is selected.
