Gigabyte C621-WD12-IPMI (rev. 1.0) [13/47] Mic in side speaker out
![Gigabyte C621-WD12-IPMI (rev. 1.0) [13/47] Mic in side speaker out](/views2/1679929/page13/bgd.png)
Mic In/Side Speaker Out
The Mic in jack.
• When removing the cable connected to a back panel connector, rst remove the cable from
your device and then remove it from the motherboard.
• When removing the cable, pull it straight out from the connector. Do not rock it side to side to
prevent an electrical short inside the cable connector.
• If you want to install a Side Speaker, you need to retask either the Line in or Mic in jack to be
Side Speaker out through the audio driver.
• To enable or congure the audio amplifying function for the Line out jack, please access the
HD Audio Manager application.
Audio Jack Congurations:
Jack
Headphone/
2-channel
4-channel 5.1-channel 7.1-channel
Center/Subwoofer Speaker
Out
a a
Rear Speaker Out
a a a
Line In/Side Speaker Out
a
Line Out/Front Speaker Out
a a a a
Mic In/Side Speaker Out
a
- 13 -
