10) TBT
1
5
Pin Denition
1 FORCE_POWER
2 SCI_EVENT
3 SLP_S3
4 SLP_S5
5 GND
Pin Denition
1 BMC_UART_TXD
2 GND
3 BMC_UART_RXD
4 Power (5V)
1
11) BMC_UART *
Pin Denition
1 Power (5V)
2 GND
3 NA
1
12) SATA_DOM0 (SATA DOM0 Power Header)
13) SATA_DOM1 (SATA DOM1 Power Header)
Pin Denition
1-2 SMB to PCH
2-3 SMB to BMC
1
14) VRM_SCL (For VRM SMB_CLK)
15) VRM_SDA (For VRM SMB_DATA)
* Only for the GA-C621-WD12-IPMI.
- 17 -
