![Gigabyte C621-WD12-IPMI (rev. 1.0) [22/47] Pwr_sw power button 33 rst_sw reset button](/img/pdf.png)
Gigabyte C621-WD12-IPMI (rev. 1.0) [22/47] Pwr_sw power button 33 rst_sw reset button
![Gigabyte C621-WD12-IPMI (rev. 1.0) [22/47] Pwr_sw power button 33 rst_sw reset button](/views2/1679929/page22/bg16.png)
Pin Denition Pin Denition
1 NA 2 -
3 SATA_DATA 4 GND
5 GND 6 SATA_LOAD
7 NA 8 SATA_CLK
2
8
1
7
34) S_SGPIO (For S-SATA0~1)
32) PWR_SW (Power Button)
33) RST_SW (Reset Button)
35) F_AUDIO
12
910
36) VGA (Supported by the BMC) *
12
1516
Pin Denition Pin Denition
1 VGA-R 2 VGA-G
3 VGA-B 4 NA
5 GND 6 GND
7 GND 8 GND
9 5V 10 GND
11 NA 12 DDC_DATA
13 H_SYNC 14 V_SYNC
15 DDC_CLK 16 -
* Only for the GA-C621-WD12-IPMI.
- 22 -
