28) S-SATA0~1 (SATA 6Gb/s Connectors, Supported by the Intel
®
PCH)
29) I-SATA0~7 (SATA 6Gb/s Connectors, Supported by the Intel
®
PCH)
30) PCIEX4_M2 (M.2 Socket 3 Connectors)
11042 60 80
31) U2_1~2 (U2 Connector)
- 21 -
