1-2 ProductSpecications
CPU Support for Intel
®
Xeon
®
Scalable Processors in the LGA 3647 package
Dual Socket P (Square) with 2 UPI support of up to 10.4 GT/s, CPU TDP support
up to 205W
Chipset Intel
®
C621 Chipset
Memory 12 x DDR4 DIMM sockets supporting up to 1.5 TB of system memory
6 channel memory architecture (6 channel per CPU)
Support for DDR4 2666 MHz memory modules if use a Skylake CPU
Support for DDR4 2933 MHz memory modules if use a Cascade lake CPU
Support for ECC RDIMM/RDIMM 3DS/LRDIMM/LRDIMM 3DS memory modules
Audio Realtek
®
ALC1220-VB codec
High Denition Audio
2/4/5.1/7.1-channel
Support for S/PDIF Out
LAN 2 x Intel
®
210AT GbE LAN chips (10/100/1000 Mbit)
Expansion Slots 4 x PCI Express x16 slots, running at x16
3 x PCI Express x16 slots, running at x8
(All of the PCI Express x16 slots conform to PCI Express 3.0 standard.)
Storage Interface Chipset:
- 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and
PCIe x4/x2 SSD support)
- 8 x SATA 6Gb/s connectors (I-SATA0~I-SATA7)
- 2 x SATA 6Gb/s connectors (S-SATA0, S-SATA1)
- 2 x U.2 connectors
- Support for RAID 0, RAID 1, RAID 5, and RAID 10
USB Chipset:
- 1 x USB Type-C
™
port on the back panel, with USB 3.1 Gen 2 support
- 1 x USB 3.1 Gen 2 Type-A ports (red) on the back panel
- 7 x USB 3.1 Gen 1 ports (4 ports on the back panel, 1 port onboard, 2 ports
available through the internal USB header)
- 2 x USB 2.0/1.1 ports available through the internal USB header
Internal
Connectors
1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
1 x 6-pin ATX 12V power connector
2 x CPU fan headers
5 x system fan headers
1 x M.2 Socket 3 connector
10 x SATA 6Gb/s connectors
2 x U.2 connectors
2 x SATA DOM power headers
1 x PMBus connector
1 x Intel
®
VROC Upgrade Key header
1 x front panel header
1 x front panel audio header
1 x USB 3.1 Gen 1 header
1 x USB 3.1 Gen 1 port
