Internal

Connectors

 1 x USB 2.0/1.1 header

 1 x Trusted Platform Module (TPM) header

 1 x serial port connector

 1 x chassis intrusion header

 3 x SATA SGPIO headers

 1 x SMD_VMD header

 1 x IPMB connector *

 1 x SMB connector

 1 x TBT connector

 1 x BMC_UART connector *

 1 x VGA connector *

 1 x wake on LAN header

 1 x speaker header

 1 x Clear CMOS jumper

 1 x VGA jumper *

 1 x Watch-Dog timer jumper *

 1 x VRM SMB Clock jumper

 1 x VRM SMB Data jumper

 1 x power button

 1 x reset button

Back Panel

Connectors

 1 x PS/2 keyboard/mouse port

 1 x USB Type-C

™

port, with USB 3.1 Gen 2 support

 1 x USB 3.1 Gen 2 Type-A port (red)

 4 x USB 3.1 Gen 1 ports

 2 x USB 2.0/1.1 ports

 2 x RJ-45 ports

 1 x optical S/PDIF Out connector

 5 x audio jacks

I/O Controller  ASPEED

AST2500 BMC chip

Hardware

Monitor

 Voltage detection

 Temperature detection

 Fan speed detection

 Fan speed control

* Whether the fan speed control function is supported will depend on the fan you install.

BIOS  1 x 256 Mbit ash

 Use of licensed AMI BIOS

 PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Operating

Properties

 Operating temperature: 10°C to 40°C

 Operating humidity: 8 - 80%

 Non-operating temperature: -40°C to 70°C

 Non-operating humidity: 5% - 95%

Form Factor  EEB Form Factor; 30.5cm x 33.0cm

* GIGABYTE reserves the right to make any changes to the product specications and product-related information without

prior notice.

- 9 -

* Only for the GA-C621-WD12-IPMI.
