Remote Control
On this page, you can remote control your host system on BIOS Setup or Operating System.
Settings
This page allows you to congure BMC options. The options are: Captured BSOD, Date & Time, External
User Services, KVM Mouse Setting, Log Settings, Media Redirection Settings, Network Settings, PAM Order
Settings, Platform Event Filter, Services, SMTP Settings, SSL Settings, System Firewall, User Management,
and Video Recording.
