4
Fatal1ty X79 Professional Series Motherboard
English
Motherboard Layout
1 2 x 240-pin DDR3 DIMM Slots 24 Dr. Debug
(DDR3_A1, DDR3_B1, Black) 25 Clear CMOS Jumper (CLRCMOS1)
2 2011-Pin CPU Socket 26 Intel X79 Chipset
3 ATX 12V Power Connector (ATX12V1) 27 USB 2.0 Header (USB_10_11, Black)
4 2 x 240-pin DDR3 DIMM Slots 28 USB 2.0 Header (USB_8_9, Black)
(DDR3_D1, DDR3_C1, Black) 29 USB 2.0 Header (USB_6_7, Black)
5 CPU Fan Connector (CPU_FAN1) 30 Consumer Infrared Module Header
6 CPU Fan Connector (CPU_FAN2) (CIR1, Gray)
7 ATX Power Connector (ATXPWR1) 31 SLI / XFIRE Power Connector
8 USB 3.0 Header (USB3_5_6, Black) 32 COM Port Header (COM1)
9 USB 3.0 Header (USB3_7_8, Black) 33 HDMI_SPDIF Header
10 SPI Flash Memory (64Mb) (HDMI_SPDIF1, Black)
11 Chassis Fan Connector (CHA_FAN1) 34 Front Panel IEEE 1394 Header
12 SATA2 Connectors (SATA2_2_3, Black) (FRONT_1394, Black)
13 SATA2 Connectors (SATA2_0_1, Black) 35 Front Panel Audio Header
14 SATA3 Connectors (SATA3_0_1, Red) (HD_AUDIO1, Black)
15 SATA3 Connectors (SATA3_M0_M1, Red) 36 PCI Express 3.0 x16 Slot (PCIE5, Red)
16 SATA3 Connectors (SATA3_M2_M3, Red) 37 Infrared Module Header (IR1)
17 Chassis Fan Connector (CHA_FAN3) 38 PCI Slot (PCI2, Black)
18 Power Switch (PWRBTN) 39 PCI Express 3.0 x16 Slot (PCIE4, Red)
19 Reset Switch (RSTBTN) 40 PCI Express 2.0 x1 Slot (PCIE3, Black)
20 Chassis Fan Connector (CHA_FAN2) 41 PCI Express 3.0 x16 Slot (PCIE2, Red)
21 Chassis Speaker Header (SPEAKER1, Black) 42 PCI Slot (PCI1, Black)
22 System Panel Header (PANEL1, Black) 43 PCI Express 3.0 x16 Slot (PCIE1, Red)
23 Power LED Header (PLED1) 44 Power Fan Connector (PWR_FAN1)
DDR3_D1 (64 bit, 24 0- pi n mo du le )
DDR3_C1 (64 bit, 24 0- pi n mo du le )
ATX12V1
DDR3_A1 (64 bit, 24 0- pi n mo du le )
DDR3_B1 (64 bit, 24 0- pi n mo du le )
ATXPWR1
24.4cm (9.6 in)
30.5cm (12 .0 in )
Intel
X79
Dr.
Debug
RSTBTN1
PWRBTN1
SATA3_M 2_M3
SATA3_M 0_M1
SATA2_2 _3
SATA2_0 _1
SATA3_0 _1
64Mb
BIOS
CMOS
Battery
PCIE3
PCIE1
PCIE2
PCIE4
PCIE5
PCI1
PCI2
Sup er
I/O
SLI/XFIRE_PWR1
AUDIO
CODEC
PLED1
1
1
SPEAKER1
HDLED RESET
PLED PWRBTN
PANEL1
1
CHA_FAN2
CHA_ FAN1
CPU_FA N2
CPU_FAN1
CHA_ FAN3
USB 2 .0
T: USB0
B: US B1
PS2
Key board
Clr
CMOS
Coaxial
SPDIF
Optical
SPDIF
USB 3.0
T: USB1
B: USB2
Top:
IEEE
1394
USB 2.0
T: USB2
B: USB3
Top:
RJ-45
USB 2.0
T: USB4
B: USB5
eSATA 3
USB 3.0
T: USB3
B: USB4
eSATA 3
Top:
SIDE S PK
Cent er:
REAR S PK
Bott om:
CTR BA SS
Top:
LINE I N
Cent er:
FRON T
Bott om:
MIC IN
1
HDMI_SPDIF1
1
HD_AUDIO1
FRONT_1394
1
COM1
1
IR1
1
USB_6_7
1
CIR1
1
USB_8_9
1
USB_10_11
1
CLRCMOS1
1
LAN
PHY
1
1
X79 Professional
FATAL1TY
2 oz Copper PCB
XF ast USB
XF ast LAN
PCI Express 3.0 Ready
4-Way SLI
USB 3.0
Front USB 3.0
1394a
SATA3 6Gb/s
ErP/EuP Rea dy
RoHS
4 Channels DDR3
DDR3 2400 +
Designed in Taipei
USB3 _5_6
USB3 _7_8
PWR_FAN1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
2324
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
