Fatal1ty Z77 Professional-M Series Motherboard
Português
1.2 Especificações
Plataforma - Formato Micro ATX: 9,6 pol. x 9,6 pol., 24,4 cm x 24,4 cm
- Design de condensadores banhados a ouro de alta qualidade
(Condensadores de polímeros condutores de alta qualidade
100% fabricados no Japão)
CPU - Suporta Intel
®
Core
TM
i7 / i5 / i3 de 3ª e 2ª geração no pacote
LGA1155
- Design de Poder Digital
- Alimentação de 8 + 3 fases
- Suporta a tecnologia Intel
®
Turbo Boost 2.0
- Suporta K-Series desbloqueado CPU
- Suporta a tecnologia Hyper-Threading (veja o AVISO 1)
- Suporta a tecnologia Rapid Start da Intel
®
e a tecnologia
Smart Connect com CPU Ivy Bridge da Intel
®
Chipsets - Intel
®
Z77
Memória - Suporte à tecnologia de memória de duplo canal
(veja o AVISO 2)
- 4 x slots de DDR3 DIMM
- Suporta memória DDR3 2800+(OC)/2400(OC)/2133(OC)/1866
(OC)/1600/1333/1066, não ECC, sem tampão
- Capacidade máxima de memória do sistema: 32GB
(veja o AVISO 3)
- Suporta Extreme Memory Prole (XMP)1.3/1.2 da Intel
®
Slots de - 2 x slots de PCI Express 3.0 x16 (PCIE1/PCIE3: individual nas
Expansão versões x16 (PCIE1) / x8 (PCIE3) ou dupla na versão x8/x8)
(veja o AVISO 4)
* O modo PCIE 3.0 apenas é suportado com a CPU Ivy Bridge
da Intel
®
A CPU Sandy Bridge da Intel
®
apenas suporta o
modo PCIE 2.0.
- 1 x slot de PCI Express 2.0 x16 (PCIE4 modo @ x4)
- 1 x slot de PCI Express 2.0 x1
- Suporta Quad CrossFireX
TM
, 3-Way CrossFireX
TM
e
CrossFireX
TM
da AMD
- Suporta Quad SLI
TM
e SLI
TM
da NVIDIA
®
VGA integrado * As saídas Intel
®
HD Graphics Built-in Visuals e VGA são
suportadas apenas por processadores com GPU integrada.
- Suporta Intel
®
HD Graphics Embutido Visuals: Intel
®
Quick
Sync Video, Intel
®
InTru
TM
3D, Intel
®
Clear Video HD
Technology, Intel
®
Insider
TM
, Intel
®
HD Graphics 2500/4000,
Intel
®
Advanced Vector Extensions (AVX)
