Fatal1ty Z77 Professional-M Series Motherboard
23
English
Step4. Connect a VGA cable or a DVI cable to the monitor connector or the DVI
connector of the graphics card that is inserted to PCIE1 slot.
Step3. Align and insert ASRock SLI_Bridge Card to the goldfingers on each
graphics card. Make sure ASRock SLI_Bridge Card is rmly in place.
ASRock SLI_Bridge Card
