Daikin MC707VM-W [10/61] Specifications
![Daikin MC707VM-W [10/61] Specifications](/views2/1694146/page10/bga.png)
SiENBE81-623A Specifications
Photocatalytic Air Purifiers 9
3. Specifications
3.1 Specifications
NOTE:
"1. Deodorizing efficiency means the combined removal rate of ammonia, acetaldehyde and acetic acid after burning five
cigarettes in a 1m
3
airtight container and running the air purifier at rated air flow for one minute.
"2. Operating sound levels are the average of values measured at 1m away from the front, left, right and top of the unit.
(This equal to the value in an anechoic chamber.)
The values are measured without bio-antibody filter.
Model MC707VM-S MC707VM-W
Type Photocatalytic air purifier
Power supply
1
φ 220-240 / 220-230V 50 / 60Hz
Color
Sparkling silver
+ metallic ocean blue
White
+ Sparkling silver
Rated power consumption
(HH/H/M/L/LL)
W 55 / 23 / 14 / 10 / 8
Running current
(HH/H/M/L/LL)
A 0.48 / 0.22 / 0.14 / 0.10 / 0.08
Deodorizing Efficiency
(JEM1467"1)
%95
Operating sound "2
(HH/H/M/L/LL)
dBA 47 / 38 / 31 / 24 / 16
Sound power "2
(HH/H/M/L/LL)
dBA 62 / 52 / 40 / 39 / 31
Fan
Type Multi blade fan (Sirocco fan with shroud assembly)
Air flow rate
(HH/H/M/L/LL)
m
3
/h
420 / 285 / 180 / 120 / 60
Dust collecting method
Plasma ionizer (Electrostatic dust collection) + Electrostatic
dust collection filter
Deodorizing method
Flash streamer + Titanium apatite photocatalytic
filter + Deodorizing catalyst
Bacteria filtering method
Bio-antibody filter + Flash streamer + Titanium apatite
photocatalytic filter
Safety device
Safety switch
(Operation stops when the front panel is open.)
Power cord m 2.0
Dimensions (H x W x D) mm 533 x 425 x 213
Package dimensions (H x W x D) mm 587 x 478 x 263
Product weight kg 8.7
Gross weight kg 11.0
Standard accessories
Operation manual (1), Wireless remote control (1),
Photocatalytic pleated filter (7), Bio-antibody filter (1)
Drawing number 3D051236 3D051237
