Introduction SiENBE81-623A
4 Photocatalytic Air Purifiers
Only flash streamer removes adjuvants.
Diesel exhaust(DPE)
Adjuvants are substances included in air pollutants such as
exhaust gas that, when inhaled along with allergens, make one's
allergy symptoms worsen.
Allergens
Adjuvant
Allergy symptoms
worsen.
Allergy symptoms
worsen.
Adjuvant
Diesel exhaust(DPE)
Allergens
Pollen
Mites
Pollen
Mold
and others
Diesel exhaust
particles
Exhaust gas
(NOx, formaldehyde,
etc.)
VOC
(toluene,xylene, etc.)
and others
Only flash streamer removes adjuvants.
06CJG-8
06CJG-9
95%
deodorizing efficiency
Powerfully breaks down odors in 3 stages!
95%
deodorizing efficiency
Plasma
ionizer
Odor
molecules
Electrostatic dust
collection filter
Purified air
Flash
streamer
Flash streamer
X
Titanium Apatite
Photocatalytic Filter
Flash streamer
X
Streamer
deodorizing
catalyst
06CJG-10
Disinfection
Titanium Apatite
Photocatalyst
Almost all
removed
after 24 hrs.
The Flash Streamer
further activates the
photocatalyst!
