![Daikin ACEF4AV1-H [3/64] Safety cautions](/views2/1694155/page3/bg3.png)
SiE-64 Safety Cautions
iii
1. Safety Cautions
1.1 Cautions and Warnings
Read the following warnings and cautions BEFORE operating the system and use it correctly.
This manual classifies the precautions to the user into the following two categories.
Each mention important cautions on safety, so be sure to keep them.
WARNING Failure to follow a warning is very likely to result in such grave consequences as death or serious
injury.
CAUTION Failure to follow a caution may result in serious injury or property damage, and in certain
conditions, may result in a grave consequence.
The pictograms in the text show the following meanings.
Absolutely prohibited
Be sure to operate following instructions
Be sure to unplug the power cable
After reading, keep this manual in a place where the actual user can see it whenever necessary. And in
case of changing user, be sure to hand it to the new user.
Warning
Do not disassemble, service or
modify this equipment.
Unwarranted tempering can lead to fire
and/or malfunction.
Do not operate the equipment with
wet hands.
Otherwise electrical shock can result.
Use only 220-240 VAC 50 Hz power
supply.
Otherwise fire and electrical shock can
result.
Do not use the power cable if it is
damaged.
Using a damaged power cable is
extremely hazardous; if the power cord
becomes damaged, you must obtain a
replacement from the manufacturer or
from a properly-authorized service
agent.
Before changing filters, cleaning the
equipment or moving it, turn it OFF
and unplug the power cable.
Working with power ON can lead to fire
and/or electric shock.
Do not use the power cable if
damaged or loose in the socket.
Using the power cable in anything but
proper working condition can lead to
short-circuits and subsequently electric
shock and/or fire.
Si-64.book Page iii Monday, June 18, 2001 2:57 PM
