Daikin ACEF4AV1-H [42/64] Removal of ionizing wire
![Daikin ACEF4AV1-H [42/64] Removal of ionizing wire](/views2/1694155/page42/bg2a.png)
In Case of ACEF4AV1-(C)(H) SiE-64
36 Removal Procedure
1.2 Removal of Ionizing Wire
Procedure Warning Be sure to turn off all power supplies before disassembling work
Step Procedure Points
1 Push the hook using (-)
screw driver to remove
ionizing wire fixing plate.
2 Remove ionizing wire
3 Peel off sealing strips at top
of main body.
Si-64.book Page 36 Monday, June 18, 2001 2:57 PM
