Daikin ACEF4AV1-H [40/64] Removal procedure
![Daikin ACEF4AV1-H [40/64] Removal procedure](/views2/1694155/page40/bg28.png)
In Case of ACEF4AV1-(C)(H) SiE-64
34 Removal Procedure
3 Remove front panel
4 Disengage hooks located at
four of corners of the filter to
remove prefilter located at
rear side of panel.
5 Remove ion-roll filter case
Step Procedure Points
Si-64.book Page 34 Monday, June 18, 2001 2:57 PM
