In Case of ACEF4AV1-(C)(H) SiE-64
38 Removal Procedure
4 Turn main body over, then
remove back panel.
5 Disconnect CN2 connector
located at bottom left of main
body rear side.
Step Procedure Points
Si-64.book Page 38 Monday, June 18, 2001 2:57 PM
