In Case of ACEF4AV1-(C)(H) SiE-64
40 Removal Procedure
1.4 Removal of PCB
Procedure Warning Be sure to turn off all power supplies before disassembling work
Step Procedure Points
1 Dismount a screw located at
bottom right of main body to
remove display box.
2 Disengage 10 hooks.
3 Disengage the hooks to
remove display PCB.
Si-64.book Page 40 Monday, June 18, 2001 2:57 PM
