11
GB
Technical information
COMMON FEATURES FOR ALL MODELS
WITH ELECTRIC HOTPLATES AND AUTO-
MATIC IGNITION
The supply voltage and frequency will be
as shown on the rating plate.
If an electric hotplate gets cracked, the
hob should be disconnected from the elec-
tricity current.
COMMON FEATURES FOR ALL
MODELS WITH GAS BURNERS
Warnings:
a) Before installation, make sure that the
local supply conditions (the gas type and
pressure) are compatible with the applian-
ce’s setup.
b) The setup conditions for this appliance
are written on the label (or the rating plate).
c) This appliance should not be connected
to a device for removing combustion pro-
ducts. It should be installed and connected
in compliance with the current installation
standards. Special attention should be paid
to the regulations applying to ventilation.
A gas cooking appliance produ-
ces heat and moisture at the site where
it is installed. The kitchen should be
provided with suitable ventilation: natu-
ral ventilation sources should be kept
clear, a window opened, or an effective
mechical ventilation system device,
such as a hood, installed.
If the appliance is used intensi-
vely over a sustained period of time, it
may require supplementary ventilation,
such as an open window, or more effec-
tive ventilation, for example an increa-
se in the power of the mechanical ven-
tilation, if this is present.
You should keep the Guarantee
Certificate or, where relevant, the techni-
cal datasheet, together with the Instruc-
tion Manual for the duration of the useful
life of the appliance. It has important tech-
nical information about the appliance.
Table 3
Burner
Nominal Calorific Consumption
Nominal Consumption*
Reduced calorific consumption
Performance
* Consumption over Gross Calorific Value (H )
Auxiliary
1
0,10
0,07
0,07
0,33
-
Rapid
3
0,29
0,22
0,21
0,77
>52
s
kW
G-20 (Nm
3
/h)
G-30 (Kg/h)
G-31 (Kg/h)
mbar
20
29
37
kW
%
Country
Spain
Portugal
United Kingdom
Switzerland
Ireland
Chez Republic
Greece
Hungary
Denmark
Norway
Finland
Sweden
Category
II2H3+
II2H3+
II2H3+
II2H3+
II2H3+
II2H3+
I3+
I2H
I2H
I2H
I2H
I2H
Table 2
Class 3 hob.
