GB
9
located lower down, and on the guarantee
certificate or, where appropriate, the tech-
nical datasheet supplied, which should be
kept together with this manual.
The connection is made via an omnipolar
switch or plug where accessible, which is
suitable for the intensity to be tolerated
and which has a minimum gap of 3 mm
between its contacts, which will ensure
disconnection in case of emergency or
when cleaning the hob.
The connection should include correct ear-
thing, in compliance with current norms.
If the flexible supply cable fitted to these
appliances ever needs to be changed, it
should be replaced by TEKA’s official service.
The input cable should not be in contact
either with the body of the hob or with the
body of the oven, if the oven is installed in
the same unit.
Gas conversion
Important!
Any alteration that is to be made to the
appliance to convert it to a different
type of gas should only be carried out
by an authorised person and should
comply with current standards.
Information for Technical
Assistance: whenever the type of gas or
the appliance’s pressure is changed, the
new regulation plate should be placed on
top of the old one so that the new features
can be seen after the change.
The tasks involved in conversion are:
* Replace the injectors.
* Adjust the taps’ minimums.
The injectors required for each gas type
are shown in table 1.
To replace the injectors, follow these ins-
tructions:
1 Remove the grids and upper parts of the
burner so that the injector can be seen.
2 Using a number 7 pipe spanner, remove
the injectors and replace them with the
new ones. Take good care to tighten the
injector properly and so avoid gas esca-
ping.
3 Replace the grid and burners that were
previously removed.
When the injectors have been changed,
this is how to adjust the minimums:
1 Turn the burners on to their minimum.
2 Remove the cooker’s controls in order to
be able to access the gas taps.
3 Use a slim, grooved screwdriver to turn
the screw located to the left or in the
centre of the gas tap’s shaft (the flame
increases when you turn to the left and
decreases when you turn to the right).
4 When properly adjusted, check that the
flame does not go out when you turn the
knob quickly from maximum to mini-
mum.
TEKA INDUSTRIAL, S.A. assumes no
responsibility for any hob malfunction if the
gas conversion or the adjustment of the
burners’ minimums has not been carried
out by TEKA’s official personnel.
Ø injector expressed in 1/100 mm.
Burner
Rapid
Auxiliary
Table 1
Family
Third
Group 3+
85
50
Group H
116 Y
72 X
Group E+
116 Y
72 X
Second
