25 26
Indoor Unit Lineup
VRV Indoor Units
Ceiling Concealed (Duct) Type
High static pressure offers flexible duct design
that blends in with any interior décor in stores and offices
FXDYQ80MA / FXDYQ100MA
FXDYQ125MA / FXDYQ145MA
FXDYQ180M / FXDYQ200M / FXDYQ250M
Quiet yet powerful supply air fan.
High external static pressure allows
comprehensive duct layout for various
applications.
Two external static pressure settings for
added flexibility.
High efficiency Hi-X heat exchanger
coils that provide even more energy
savings.
Design of indoor units allows installation
in limited roof spaces.
Return air spigots included for ease of
installation for FXDYQ80MA-145MA
models.
High strength galvanised steel casing.
120 Pa for FXDYQ80MA–145MA
150 Pa for FXDYQ180M
180 Pa for FXDYQ200M
200 Pa for FXDYQ250M
Middle Static Pressure Ceiling Mounted Duct Type
Design flexibility
Comfort
Easy maintenance
Easy installation
*30 Pa–150 Pa for FXSQ20-40PVE
50 Pa–150 Pa for FXSQ50-125PVE
50 Pa–140 Pa for FXSQ140PVE
Comfortable airflow is achieved in accordance with
conditions such as duct length.
Adjustable external static pressure
30 Pa* 150 Pa
Set to high static pressure for
advanced needs such as when
using dampers and long ducts.
Set to low static
pressure when ducts
are short.
Adjustable external static pressure
(dB(A))
Switchable airflow rate
Auto airflow rate
Drain pan maintenance check hole
Separate drain pipe
and inspection opening
Airflow rate auto adjustment function
Using a DC fan motor, the external static pressure can
be controlled within a range of 30 Pa* to 150 Pa.
Control of the airflow rate can be selected from 3-step
control.
5-step airflow rate is
automatically controlled in
accordance with the difference
between room
temperature and set
temperature.
Auto airflow rate control can be
selected with wired
remote controller BRC1E62.
During installation, even if the external static pressure
changes due to a change in the duct route, the airflow
can be automatically adjusted to within the unit’s
external static pressure range.
Airflow rate can be controlled using a remote
controller during test operation. It is automatically
adjusted to the range between approximately ±10% of
the rated H tap airflow.
Inspection and cleaning is facilitated by separating the
drain pipe and inspection opening and by the
drain pan maintenance check hole.
The drain pan can be detached for easy cleaning.
(The lifespan of a silver ion cartridge depends
on the usage environment, but should be
changed once every two to three years.)
36/32/29
63
34/32/29
50
36/33/30
40
34/32/30
32
33/30/28
20/25
Sound level
(H/M/L)
FXSQ-PVE
43/40/36
140
42/38.5/35
125
39/35/32
100
37.5/34/30
80
Sound level
(H/M/L)
FXSQ-PVE
Low operation sound level
An antibacterial treatment that uses silver ions has
been applied to the drain pan, preventing
the growth of slime, mould and bacteria
that cause blockages and odours.
