Control Systems
57 58
Individual Control Systems for
VRV
Indoor Units
“Nav Ease” (Wired remote controller) (Option)
Clear display
Dot matrix display
A combination of fine dots enables various
icons.Large text display is easy to see.
Backlight display
Backlight display helps operating in
dark rooms.
Simple operation
Guide on display
The display gives an explanation of each setting for easy operation.
Large buttons and arrow keys
Large buttons and arrow keys enable easy operation. Basic setting such as fan
speed and temperature can be intuitively operated. For other settings just select
the function from the menu list.
Auto airflow rate (*2)
Airflow rate is automatically controlled in accordance with the difference between room temperature and set temperature.
Setback (default:OFF)
Maintains the room temperature in a specific range during unoccupied period
by temporarily starting air conditioner that was turned OFF.
Ex) Setback temperature Cooling : 35ºC Recovery differential Cooling : -2ºC
When the room temperature goes above 35ºC, the air conditioner starts operating in Cooling automatically.
When room temperature reaches 33ºC, the air conditioner returns OFF.
Cooling
Setback
temperature
Recovery
differential
33 -2
37ºC -8ºC
Heating 10 +2
15ºC +8ºC
Individual airflow direction (*1)
Airflow direction of each of the four air outlets can be controlled individually.
(Positions 0 to 4, Swing, and No individual setting are selectable.)
1 2
3
4
Outlet mark
1
2
4
3
5 actions per day can be scheduled for each day of the week.
The holiday function will disable schedule timer for the days that have been set as holiday.
3 independent schedules can be set. (e.g. summer, winter, mid-season)
Weekly schedule
The first period starts and the
air conditioner starts the cooling
operation.
College classroom sample
(a summer Monday case)
1) 8
:
30 ON
ON OFF ON OFF
In the second period, the classroom
is unoccupied and the air conditioner
stops.
2) 10
:
00 OFF
When the third period starts,
operation starts again.
3) 13
:
00 ON
After the third period, the classroom
becomes vacant again and the
air conditioner stops.
4) 15
:
00 OFF
Energy saving
Off timer
Turns off the air conditioner after a preset
period of time.
Period can be preset from 30 to 180 minutes
in 10-minute increments.
Auto operation mode
Until now only the temperature for one point could be set, but now the new
remote controller (BRC1E62) allows the setting of both Cooling and Heating,
and with the fan operation, mid-range temperatures are comfortable and
operation is more energy efficient.
Setpoint auto reset
Even if the set temperature is changed, it returns
to the preset temperature after a preset period of
time.
Period selectable from 30 min/60 min/90 min/120
min.
Restaurant sample
Restaurant opened
Temperature is set to 27ºC
Full tables at lunchtime
Then is lowered to 24ºC
for crowded room
After 30 minutes*
Automatically returns to preset
temperature (27ºC)
*Setting possible for after 30, 60, 90,
and 120 minutes.
27
°C
24
°C
Returns to
27
°C
automatically
Convenience
Comfort
Setpoint range set
Saves energy by limiting the min. and max.
set temperature.
Avoids excessive cooling or heating.
This function is convenient when the remote
controller is installed at a place where any
number of people may operate it.
BRC1E62
This simple, contemporary remote controller with fresh white colour
matches your interior design. The clear, backlight display with large
easy-to-read text makes navigation easy and provides one-touch control
over your in-home comfort.
Multingual display
11 display languages are available. (English, German, French, Spanish, Italian, Portuguese, Greek, Dutch, Russian, Turkish and Polish)
*1 Only available for VRV 4-Way Flow Ceiling Suspended type FXUQ-A series and Ceiling Mounted Cassette (Round Flow with Sensing) type FXFQ-S series.
*2 Only available for VRV 4-Way Flow Ceiling Suspended type FXUQ-A series, Ceiling Mounted Cassette (Round Flow with Sensing) type FXFQ-S series and Middle Static Pressure
Ceiling Mounted Duct type FXSQ-P series..
