27 28
Indoor Unit Lineup
VRV Indoor Units
Middle and high static pressure
allows for flexible duct design
FXMQ20P / FXMQ25P / FXMQ32P
FXMQ40P / FXMQ50P / FXMQ63P
FXMQ80P / FXMQ100P / FXMQ125P
FXMQ140P
Ceiling Mounted Duct Type
Built-in Drain Pump (Option)
Housing the drain pump inside the unit reduces the
space required for installation.
A DC fan motor increases the external static
pressure capacity range to include middle to high
static pressures, increasing design flexibility.
Indoor unit
470
mm
Indoor unit
470
mm
0–250
mm
222
mm
Without drain pump
With drain pump
Simplified Static Pressure Control
External static pressure can be easily adjusted using
a change-over switch inside the electrical box to meet
the resistance in the duct system.
FXMQ200MA/FXMQ250MA
Drain pump is equipped as
standard accessory with
700 mm lift.
Control of the airflow rate has been improved
from 2-step to 3-step control.
700 mm
Ceiling
30 Pa–100 Pa for FXMQ20P-32P
30 Pa–160 Pa for FXMQ40P
50 Pa–200 Pa for FXMQ50P-125P
50 Pa–140 Pa for FXMQ140P
Low operation sound level
Improved ease of maintenance
Improved ease of installation
25
mm
All models are only 300 mm in height, an improvement
over the 390 mm height of conventional models. The
weight of the FXMQ40P has been reduced from 44 kg
to 28 kg.
Airflow rate can be controlled using a remote controller
during test operation. With the conventional model, the
airflow rate was controlled from the PC board. It is
automatically adjusted to the range between approximately
±10% of the rated HH tap airflow for FXMQ20P–125P.
Energy-efficient
The adopted DC fan motor is much more efficient than
the conventional AC motor, yielding an approximate
20% decrease in energy consumption (FXMQ125P).
The drain pan can be detached for easy cleaning.
An antibacterial treatment that uses silver ions has
been applied to the drain pan, prevent-
ing the growth of slime, mould and
bacteria that cause blockages and
odours.
(The lifespan of the cartridge depends
on the usage environment, but should
be changed once every two to three
years.)
Ceiling Suspended Type
Slim body with quiet and wide airflow
Adoption of QUIET STREAM FAN
Drain pump kit (option) can be easily incorporated.
Easy-to-clean flat design
Maintenance is easier because everything can be
performed from below the unit.
Non-dew Flap with no implanted bristles
Uses the quiet stream fan and many
more advanced technologies.
Sound absorption
member
Turbulent flow
is produced
Straightening vane
Quiet stream fan
Installation is easy
Maintenance is easy
Drain pump kit
(built inside main unit)
600 mm
Bristle-free Flap minimises
contamination and makes
cleaning simpler.
Non-dew Flap
100
°
Wide air discharge openings produce a spreading 100°
airflow.
A long-life filter (maintenance free up to one year*) is
equipped as standard accessory.
* 8 hr/day, 25 day/month. For dust concentration of 0.15 mg/m
3
FXHQ32MA / FXHQ63MA
FXHQ100MA
FXHQ-MA
Sound level
(H/L)
Sound level
(H/L)
3232
36/3136/31
6363
39/3439/34
100100
45/3745/37
(dB(A))
Low operation sound level
