31 32
Indoor Unit Lineup
Ceiling Mounted Cassette (Compact Multi Flow) Type
Quiet, compact, and designed for user comfort
T-bar grid does not need to be cut.
Designed to fit 600 mm wide ceiling grids
Low draft performance is
designed for your comfort.
Comfortable across all areas
Low operation sound level
Option
Signal receiver unit
Note: Wireless remote
controllers and signal
receiver units are sold
as a set.
575 mm
575 mm
700 mm
700 mm
286
mm
Compact
decorative panel
T-bar
600 mm
600 mm
Ceiling panel
FFQ25B
29.5/24.5 dB (A)
FFQ35B
32/25 dB (A)
FFQ50B
36/27 dB (A)
FFQ60B
41/32 dB (A)
(H/L)
Horizontal Flow
0º
0º
Less draught
750 mm
Drain pump is equipped as standard
accessory with 750 mm lift.
Settable to 5 different levels
between
0 and 35
Settable to 5 different levels
between 0 and 60
Settable to 5 different levels
between 25 and 60
Auto-swing
between 0 and 35
Auto-swing
between 0 and 60
Auto-swing
between 25 and 60
Draft
prevention
setting
(Set on site)
(Set on site)
Standard
setting
Setting to
prevent
soiling of
ceiling
Conditioned air is distributed
evenly by Auto-swing operation.
Adjustable airflow angle to
suit all room conditions.
AUTO-SWING
0
0
0
25
60
60
0
35
25
60
35
60
5 direction
Note: Angles shown above are provided as a guide. They may differ depending on the installation site.
FFQ25B / FFQ35B / FFQ50B / FFQ60B
Residential Indoor Units with connection to BP units
Slim and smooth design suits your shallow ceiling
Signals from the wireless remote controller are
transmitted to the signal receiver.
240 mm
200 mm
Only 700 mm
CDXS-EA
Dimensions (H x W x D)
Weight
Airflow rate (H)
External static pressure
200 x 700 x 620 mm
21 kg
145 /s
30 Pa
200 x 900 x 620 mm
25 kg
40 Pa
158 /s 167 /s
C(F)DXS25
35/31/29 dB (A)
C(F)DXS35
35/31/29 dB (A)
FDXS50
37/33/31 dB (A)
FDXS60
38/34/32 dB (A)
(H/L/SL)
Low operation sound level
Home Leave Operation prevents large rises or falls in
the indoor temperature by continuing operation* while
you are sleeping or out of your home. This means that
an air-conditioned welcome awaits when you wake or
return. It also means that the indoor temperature can
quickly return to your favourite comfort setting.
Models in the CDXS-EA series are only 700 mm
in width and 21 kg in weight, so are easily
installed in limited spaces. Just 200 mm in height,
all models can be installed in rooms with as little
as 240 mm depth between the drop ceiling and
ceiling slab, making them ideal for even shallow
ceilings.
Notes:
1. To prevent an increase in operation noise, avoid installing the air suction grille
directly below the suction chamber.
2. Grilles, piping connections, ducts, and installation parts should be obtained
locally. Slim Ceiling Mounted Duct type models do not have drain-up pumps.
3. The signal receiver unit must be located near the air suction inlet, because the
unit includes a sensor that detects room temperature.
* Locally obtained parts
AIR
Air suction
grille*
Suction duct*
Signal
receiver
Air discharge duct*
Suspension bolt*
Air discharge grille*
Signal receiver wire
Length
=
1,900 mm
Chamber
AIR
Air filter
* Home Leave Operation can be selected for any temperature from 18 to
32˚C for cooling operation and 10 to 30˚C for heating operation.
* Home Leave Operation function must be set using the remote controller
when going to sleep or leaving the house, and after waking up or returning
home.
Great for
hotel use!
CDXS25EA CDXS35EA FDXS25C FDXS35C
Standard accessory
Option
Slim Ceiling Mounted Duct Type
CDXS25EA / CDXS35EA
FDXS25C / FDXS35C
FDXS50C / FDXS60C
