33 34
Indoor Unit Lineup
Residential Indoor Units with connection to BP units
Wall Mounted indoor units achieve quiet sound
levels of 22 dB (A) during cooling operation.
Intelligent Eye with its infrared sensor
automatically controls air conditioner operation
according to human movement in a room. When
there is no movement, it adjusts the temperature
by 2˚C for energy savings.
FTXS20/25
37/25/22 dB
(A)
FTXS35
39/26/23 dB (A)
FTXS50
43/34/31 dB (A)
FTXS60
45/36/33 dB (A)
FTXS71
46/37/34 dB (A)
(H/L/SL)
When you are in the room
When you go out
Titanium apatite is a photocatalytic material with
high adsorption power. Titanium apatite also
effectively adsorbs and decomposes bacteria
across its entire surface. The photocatalyst is
activated simply by exposure to light.
These filters are not medical devices. Benefits
such as the adsorption and decomposition of
bacteria are only effective for substances that are
collected on and in direct contact with the Titanium
Apatite Photocatalytic Air-Purifying Filter.
Bacteria Removal Test
Testing method: dropping method
Result certificate: No. 012553-1 and 012553-2
Testing organisation: Japan Spinners Inspecting Foundation
Titanium Apatite
Photocatalytic
Air-purifying Filter
Air filter
Catches dust
Standard
accessory
Standard
accessory
FTXS20K / FTXS25K / FTXS35K
FTXS50KA / FTXS60KA / FTXS71KA
Option
Option
Stylish flat panel harmonises with your interior décor
Comfort Airflow Mode prevents uncomfortable drafts from
blowing directly on to your body. With this function, when
you press the COMFORT button during cooling
operation, the flap moves upward to prevent direct cold
drafts. During heating operation, it also moves downward
to prevent direct drafts and deliver warm air to the floor.
Cooling operation Heating operation
Wall Mounted Type
3D Airflow
3D Airflow combines Vertical and Horizontal Auto-Swing
to reduce indoor temperature fluctuation. This function
circulates air to every part of a room for uniform cooling
or heating of even large spaces. To start 3D Airflow,
push both the Vertical and Horizontal Auto-Swing
buttons. The flaps and louvers swing in turn.
Two-Area Intelligent Eye
A combination of Comfort Airflow Mode and Intelligent
Eye directs airflow away from people to avoid drafts. If
there is no movement in a room for 20 minutes,
Intelligent Eye automatically adjusts the set
temperature by approximately 2°C to save energy.
Area 2
Area 1
If a person is detected in area 1, airflow is
directed away from him/her.
Area 2
Area 1
If a person is detected in area 2, airflow is
directed away from him/her.
Elegant Appearance with Curved Panel
The sleek design of the CTXG-P indoor unit features
a uniquely European style. This elegant body
houses state-of-the-art technology which delivers
superior performance. The CTXG-P series offers a
versatile choice for home-owners, designers and
architects alike.
Comfort Airflow Mode
Comfort Airflow Mode prevents uncomfortable drafts
from blowing directly on to a person’s body. During
cooling operation, the flap moves upwards to prevent
cold drafts. During heating operation, the flap turns
vertically downwards to drive warm air to the floor.
The flaps and louvers swing in turn,
expanding the comfort zone.
CTXG25P / CTXG35P / CTXG50P
Standard
accessory
Elegant appearance with European style
Wall Mounted Type
