Control Systems
59 60
Individual Control Systems for
VRV
Indoor Units
The wired remote controller supports a wide range of control functions
The same operation modes and settings as with wired remote controllers are
possible.
* Individual airflow direction, auto airflow rate and sensing sensor control can be set only via wired remote controller
BRC1E62. Cannot be set via other remote controllers.
A signal receiver unit (installed type) for a Ceiling Mounted Cassette (Round Flow,
Compact Multi Flow, Double Flow) type, Ceiling Suspended type and Wall
Mounted type is mounted into the indoor unit.
The remote controller
has centralised its
frequently used operation
selectors and switches
(on/off, operation mode,
temperature setting and
airflow volume), making
itself suitable for use in
hotel rooms or
conference rooms.
The exposed type
remote controller is fitted
with a thermostat sensor.
Signal receiver unit
(Separate type)
Wireless remote
controller
The concealed type remote controller smartly fits into a
night table or console panel in a hotel room.
Exposed type
(BRC2C51)
Concealed type
(For hotel use)
(BRC3A61)
Wireless remote controller (Option)
Signal receiver unit
(Installed type)
Signal receiver unit can be
installed on the panel
ex. Ceiling Mounted Cassette (Round Flow) type
* Wireless remote controller and signal receiver unit are sold as a set.
* Refer to page 55 for the name of each model.
Wide variation of remote controllers for VRV indoor units
*Refer to page 55 for the name of each model.
Simplified remote controller (Option)
Wireless remote controller*
(Separate type signal receiver unit)
Wireless remote controller*
(Installed type signal receiver unit)
“Nav Ease”
(Wired remote controller)
(BRC1E62)
Simplified remote controller
(Exposed type
)
(
BRC2C51)
Simplified remote controller
(Concealed type: for Hotel use
)
(
BRC3A61)
Outdoor
unit
Indoor unit
Forced OFF
input
Remote controller
Remote controller
Remote
controller
Remote
controller
Remote controller
Remote controller
Remote
controller
Remote
controller
In all the series of VRV, Cool/Heat changeover in the same refrigerant circuit can be changed by the remote
controller of the indoor unit.
One remote controller can control the
operation of max.16 indoor units at the
same time.
Group control
Equipment
related to the
central control
1 2 3 4
Heat Reclaim
Ventilator
Control of Cool/Heat
changeover
A compact signal receiver unit (separate type) to be mounted into a wall or ceiling
is included.
FXFQ-S FXFQ-P
FXZQ FXCQ FXUQ FXKQ
FXDQ-PB/NB
FXSQ
FXDQ-SP
FXDYQ FXMQ FXHQ FXAQ
FXL(N)Q
Remote control
2
The wiring of remote controller can be extended to max.
500 m and it is possible to install the remote controllers
for the different indoor units in one place.
The indoor unit can be connected by the two remote
controller, for example one in the room and the other one
in the control room, which can control the operation of
indoor unit freely.(The last command has a priority.)
Of course, the group control by two remote controller is
also possible.
Control by two remote controller
1
The operation of Heat Reclaim Ventilator can be
controlled by the remote controller of the indoor unit.
Of course, the remote controller can display the time to
clean the filter.
Control for the combined operation
3
Expansion of system control
4
The system can be expanded to add several
controllers, such as BMS, Forced OFF input and etc.
