Chapter 3: UEFI BIOS & Soware | 27

B360GT3S

• Meteor: LEDs slide at a specic frequency.

• Wave: LEDs are presented in a water wave rhythm.

• Starry sky: LEDs icker at a specic rhythm.

• Lightning: LEDs ash and slide at a specic frequency.

• Rainbow: LEDs lights to dazzling colorful rhythm.

• Aurora: LEDs shows so light and ickers lightly.

9. High/Low Speed Switch: Allows you to control the icker speed.

Note

 WithVIVIDLEDDJuserscancontrolthefourLEDlightzonesindependentlywithdierentashing

modes(LEDSPARKLE).
