Biostar B360GT3S Версия 6.x [5/79] Rear panel connectors

Chapter 1: Introducon | 5

B360GT3S

1.4 Rear Panel Connectors

Note

 HDMI/DVI-D/VGAportsonlyworkwithanIntel®integratedGraphicsProcessor.

 Maximumresoluon

HDMI:4096x2160@24Hz,compliantwithHDMI1.4

DVI-D:1920x1200@60Hz

VGA:1920x1200@60Hz



WhenusingthefrontHDaudiojackandplugintheheadset/microphone,therearsoundwillbe

automacallyDisabled.

 Themainboardsupportsthreeonboarddisplayoutputsatsamemeandthedisplayoutput

conguraoncanbeselectedinIntelgraphicsdriverulity.
