38 | APPENDIX I: Specicaons in Other Languages
German
Spezikaonen
CPU-Unterstützung
Anschluss-1151 für den 8. Intel® Core i7 / i5 / i3 / Penum / Celeron Prozessor
* 8. Generaon Intel® Core ™ Prozessor Familie unterstützt nur 300-Serie.
* Bie konsuleren Sie www.biostar.com.tw für CPU-Unterstützungsliste
Chipset INTEL® B360
Festplaenspeicher
Unterstützt zweikanaliges DDR4 2666/ 2400/ 2133/ 1866(OC)
4x DDR4 DIMM-SpeicherSlot, Max. Uterstützung bis zu 64 GB-Speicher
Jedes DIMM unterstützt nicht-ECC 4/8/16 GB DDR4-Module
* Bie konsuleren Sie www.biostar.com.tw für für Speicherunterstützung Liste.
Arbeitsspeicher
6x SATA III-Verbindung (6Gb/s) : Unterstützt AHCI
2x M.2 (M Key) Slot:
Unterstützt M.2 Typ 2242/2260/2280 SSD-Modul
(PCIE-M2_1) Unterstützt PCI-E 3.0 x4 (32Gb/s) SSD, Intel® Rapid Storage Technology &
Intel® Optane Technology
(PCIE-M2_2) Unterstützt PCI-E 3.0 x2 (16Gb/s) und SATA III (6Gb/s) SSD
LAN
Intel i219V
10/ 100/ 1000 Mb Auto-Negoaon, Halb- / Voll-Duplex-fähig
Audio-Codec
ALC1150
7.1 Kanäle, HD-Audio, Hi-Fi(Front)
USB
1x USB 3.1(Gen2) TYPE-C-Port (1 hintere I/O)
1x USB 3.1(Gen2)-Port (1 hintere I/O)
4x USB 3.1(Gen1)-Port (2 hintere I/Os und 2 via interne Header)
6x USB 2.0-Port (2 hintere I/Os und 4 via interne Header)
Erweiterungsanschlüsse
1x PCIe 3.0 x1-Slot
1x PCIe 3.0 x16-Slot (x4)
1x PCIe 3.0 x16-Slot (x16)
Hintere I/Os
1x PS/2-Keyboard / Maus
1x VGA-Port
1x DVI-D-Port
1x HDMI-Port
1x USB 3.1(Gen2) TYPE-C-Port
1x USB 3.1(Gen2)-Port
2x USB 3.1(Gen1)-Port
2x USB 2.0-Port
1x LAN-Port
6x Audio Jack
Interne I/Os
6x SATA III (6Gb/s)
2x USB 2.0-Header (jeder Header unterstützt 2 USB 2.0-Ports)
1x USB 3.1(Gen1)-Header (jeder Header unterstützt 2 USB 3.1(Gen1)-Ports)
1x 8-Pin-Stromverbindung
1x 24-Pin-Stromverbindung
1x CPU-Venlatorverbindung
2x System-Venlatorverbindung
1x Header für Frontpanel
1x Header für Frontaudio
1x Header für klares CMOS
1x S/PDIF-Auswurfsverbindung
2x Header 5050 LED
Formfaktor uATX Formfaktor, 244 mm x 230 mm
OS-Unterstützung
Windows 10(64bit)
* Biostar reserves the right to add or remove support for any OS with or without noce.
