4 | 第一章: 主板介绍
1�3 主板特性
规格
CPU支援
Socket 1151，第8代Intel® Core i7 / i5 / i3 / Pentium / Celeron处理器
* 第8代Intel®Core™处理器系列仅支持300系列
* 请访问 www.biostar.com.tw 获取CPU的支持列表
芯片组 INTEL® B360
内存
支持双通道DDR4 2666/ 2400/ 2133/ 1866(OC)
4个DDR4 DIMM插槽，最大内存容量为64GB
每个DIMM支持非ECC 4/ 8/ 16 GB DDR4内存模组
* 请访问 www.biostar.com.tw 获取内存的支持列表。
存储器
6个SATA III接口 (6Gb/s) : 支持 AHCI
2个 M.2 (M Key) 插槽:
支持 M.2 Type 2242/ 2260/ 2280 SSD模块
(PCIE-M2_1)支持 PCI-E 3.0 x4 (32Gb/s) SSD, Intel® 快速储存技术 & Intel® Optane技术
(PCIE-M2_2)支持 PCI-E 3.0 x2 (16Gb/s) & SATA III (6Gb/s) SSD
* 当使用SATA SSD模块于PCIE-M2_2插槽时，SATA3_1接口将会被禁用。
网络
Intel i219V
10/ 100/ 1000 Mb/s自适应传输模式，半双工/全双工工作模式
音效
ALC1150
8声道音频输出，支持高清音频，Hi-Fi (前)
USB
1个USB 3.1(Gen2) Type-C端口(背板1个端口)
1个USB 3.1(Gen2)端口(背板1个端口)
4个USB 3.1(Gen1)端口(背板2个端口，板载接头支持2个端口)
6个USB 2.0端口(背板2个端口，板载接头支持4个端口)
扩展槽
1个PCIe 3.0 x1插槽
1个PCIe 3.0 x16插槽 (x4)
1个PCIe 3.0 x16插槽 (x16)
背板接口
1个PS/2 键盘/鼠标接口
1个VGA端口
1个DVI-D端口
1个HDMI端口
1个USB3.1(Gen2) Type-C端口
1个USB3.1(Gen2)端口
2个USB3.1(Gen1)端口
2个USB2.0端口
1个LAN端口
6个音频插孔
板载接口
6个SATA III接口 (6Gb/s)
2个USB2.0接头(每个接头支持2个USB2.0端口)
1个USB3.1(Gen1)接头(每个接头支持2个USB3.1(Gen1)端口)
1个电源接口(8针)
1个电源接口(24针)
1个CPU风扇接头
2个系统风扇接头
1个前置面板接头
1个前置音频接头
1个清空CMOS数据接头
1个S/PDIF输出接头
2个5050 LED接头
主板尺寸 uATX Form Factor，244 mm x 230 mm
操作系统支持
Windows 10(64bit)
* 如有增加或减少任何OS支持，Biostar保留不预先通知的权利。
