APPENDIX I: Specicaons in Other Languages | 43
B450GT
Thai
คุณสมบัติ
ซีพียู
Socket AM4 รองรับโปรเซสเซอร์ Ryzen ™ 2000 และ 3000. AMD® Ryzen™ APU (Raven Ridge,
Picasso)/ Ryzen™ CPU (Summit Ridge, Pinnacle Ridge, Matisse)
* เข้าชมได้ที่ www.biostar.com.tw สำาหรับรายการซีพียูที่สนับสนุน
ชิพเซ็ต AMD® B450
หน่วยความจำา
สนับสนุน Dual Channel DDR4 1866/2133/2400/2667/2933/3200(OC)
รองรับหน่วยความจำา 4 สล็อต DDR4 DIMM สูงสุดถึง 128 GB
ทุก DIMM สนับสนุนโมดูล non-ECC 8/16/32 GB DDR4
* DDR4 - 2667 เฉพาะสำาหรับ Ryzen CPU
* เข้าชมได้ที่ www.biostar.com.tw สำาหรับรายการหน่วยความจำาที่สนับสนุน
สตอเรจ
4x SATA III พอร์ตเชื่อมต่อ (6Gb/s) : สนับสนุน AHCI & RAID 0,1,10
1x M.2 (M Key) ซ็อกเก็ต (M2_PCIE):
สนับสนุน M.2 ชนิด 2242/2260/2280 SSD โมดูล
สนับสนุน PCI-E 3.0 x4 (32Gb/s) - NVMe/AHCI SSD
1x M.2 (M Key) ซ็อกเก็ต (M2_SATA):
สนับสนุน M.2 ชนิด 2242/2260/2280 SSD
สนับสนุน SATA III (6Gb/s) SSD
* M.2 ชนิด (M2_PCIE) : แบนด์วิดท์ขึ้นอยู่กับ CPU, Ryzen is 32Gb/s ; APU is 16Gb/s.
* เมื่อสล็อต M2_SATA ว่างตัวเชื่อมต่อ SATA3 จะถูกปิดการใช้งาน.
แลน
Realtek RTL8111H
10/ 100/ 1000 Mb/s การเจรจาอัตโนมัติ, ความสามารถในการเพล็กซ์ Half / Full
ออดิโอ โคเดก
ALC887
7.1 Channels, High Denition Audio, Hi-Fi(Front)
ยูเอสบี
6x USB 3.2 (Gen1) พอร์ต (4 พอร์ตด้านหลัง I/O และ 2 พอร์ต ผ่านพอร์ตเชื่อมต่อด้านใน)
6x USB 2.0 พอร์ต (2 พอร์ตด้านหลัง I/O และ 4 พอร์ต ผ่านพอร์ตเชื่อมต่อด้านใน)
สล็อตขยายเพิ่มเติม
1x PCIe 2.0 x1 สล็อต
1x PCIe 2.0 x16 สล็อต (x4)
1x PCIe 3.0 x16 สล็อต (เมื่อใช้ APU หรือ CPU แบนด์วิดท์คือความเร็ว x8)
พอร์ต I/O ด้านหลัง
1x PS/2 คีย์บอร์ด/ เมาส
1x DVI-D พอร์ต
1x VGA พอร์ต
1x HDMI พอร์ต
1x LAN พอร์ต
4x USB 3.2 (Gen1) พอร์ต
2x USB 2.0 พอร์ต
3x Audio Jack
พอร์ต I/O ด้านใน
4x SATA III 6Gb/s พอร์ตเชื่อมต่อ
2x USB 2.0 พอร์ตเชื่อมต่อ (หัวเชื่อมต่อทุกตัวรองรับ 2 พอร์ต USB 2.0)
1x USB 3.2 (Gen1) พอร์ตเชื่อมต่อ (หัวเชื่อมต่อทุกตัวรองรับ 2 พอร์ต USB 3.2(Gen1))
1x 8-Pin Power พอร์ตเชื่อมต่อ
1x 24-Pin Power พอร์ตเชื่อมต่อ
1x พอร์ตเชื่อมต่อ CPU Fan
1x พอร์ตเชื่อมต่อ CPU น้ำาหล่อเย็น (CPU_OPT)
2x พอร์ตเชื่อมต่อระบบ Fan
1x พอร์ตเชื่อมแต่แผงด้านหน้า
1x พอร์ตเชื่อมต่อออดิโอด้านหน้า
1x พอร์ต Clear CMOS
1x พอร์ตเชื่อมต่อออก S/PDIF
1x พอร์ตเชื่อมต่อ Serial Port
2x พอร์ต LED (5V)
1x พอร์ต LED (12V)
รูปแบบจากโรงงาน ขนาน uATX จากโรงงาน, 244มม. x 244มม.
สนับสนุน OS
Windows 7(64it)/ 10(64bit)
Windows 7(64bit) สำาหรับ Summit Ridge / Pinnacle Ridge เท่านั้น
Biostar ขอสงวนสิทธิ์ในการเพิ่มหรือถอดการสนับสนุนสำาหรับระบบปฏิบัติการ OS ต่างๆ
โดยไม่ต้องแจ้งให้ทราบล่วงหน้า
