List of VRV Unit Models SiE30-408
10 Introduction
Outdoor Unit
Connection Unit (Only Necessary for FXUQ Indoor Units)
Y1
B : The unit is for European Standards
E : Unit with anti corrosion treatment
Power supply symbol
Y1 : 3 phase 380 to 415V, 50Hz YL : 3 phase 380V 60Hz
TL : 3 phase 220V, 60Hz
Indicates major design category
5 : 5HP 14 : 14 HP 22 : 22 HP 30 : 30 HP 40 : 40 HP
8 : 8 HP 16 : 16 HP 24 : 24 HP 32 : 32 HP 42 : 42 HP
10 : 10 HP 18 : 18 HP 26 : 26 HP 34 : 34 HP 44 : 44 HP
12 : 12 HP 20 : 20 HP 28 : 28 HP 36 : 36 HP 46 : 46 HP
38 : 38 HP 48 : 48 HP
Refriger
ant: R410A
No indication : R22
Indicates that this isa
RX : Cooling Only
RXY : Heat Pump
REY : Heat Recovery
MB
48Q
RXY
(V2288)
Power supply symbol
VE : Single phase 220 to 240V, 50Hz : 220V, 60Hz
Indicates major design category
Capacity Indication
Conversion to horsepower:
71 : 3HP
140 : 6HP
Type of refrigerant
Q : R410A
Type of Unit
Connection Unit.
BEV M VEQ 71
(V2864)
